WiFi Antenna 2.4Ghz, 5GB

Omnidirectional Antenna Maxlink 01-VS-M08, 8dBi 2.4GHz

Omnidirectional antenna with 8dBi gain and 2.4GHz vertical polarization for ideal use for shorter distances up to 1km. The antenna has an N-female connector.

Τεχνικά Χαρακτηριστικά:
Type of antenna: Omnidirectional
Wireless frequency: 2.4GHz
Antenna gain: 8dBi
RF connectors: N female
Impedance: 50Ω
Designed for mast diameter: 28 up to 50mm
Purpose: Outdoor
Material: Fiberglass
Depth: 8mm
Width: 15mm
Height: 430mm
MIMO, SISO: 1x1
VSWR: <1,7
Beam angle horizontal.: 360°
Beam angle vertical: 7°

Panel antenna for wireless network
Frequency 2.4GHz-2.5GHz
Bandwidth 100 MHz
Gain 16dBi
F/B Ratio-dB: >=25
VSWR <=1.5
Ω:50
Polarization: Vertical
100W Max
Connectivity : Ν Θηλυκό
Vertical bandwidth: 15 μοίρες
Horizontal bandwidth: 60 μοίρες

Maxlink 02-SE-MM-21 Antenna sector MIMO 21-19dBi 5GHz, 60-120°

Professional MaxLink MIMO sector antenna, which allows adjusting the beam angle of 60, 90 or 120 degrees. This antenna has a rugged mount which can withstand the most adverse weather conditions.

INT-IH-G0405-F2460-V is a modern dual-band omnidirectional HORIZON series antennas are a perfect solution for an areas, where number of subscriber units are exceptionally high. These days, when band utilization growing very fast, the proper coverage is a key to success. So when you want your service stable - HORIZON series antennas mean irreplaceable solution. The antenna has been designed to work in one of two bands, 2.4Ghz or 5Ghz with gain 4dBi.

Electrical:
Type Omni
Band 2400-2500MHz 4800-6000MHz
Gain For 2.4Ghz - 4dBi For5Ghz - 5dBi
VSWR(max) 1.70:1
Half Power Beam Width (-3dB) - horizontal For 2.4Ghz 360° For 5Ghz 360°
Half Power Beam Width (-3dB) - vertical For 2.4Ghz 35° For 5Ghz 35°
DC Ground No
Impedance 50Ω

Mechanical



Connector N female
Mounting Diameter 38...51mm
Dimensions 190x26mm
Weight 0.25kg
Enviroment Outdoor, Indoor
Windload 16N (170km/h)
IP Rating IP64

Outdoor omni-directional antenna TL-ANT2412D operates in the 2.4-2.5 GHz band and provides 12dBi omni-directional operation, which largely extends the wireless range and delivers much better wireless performance. The antenna offers the N female connector guaranteeing wider compatibility with most of the wireless equipments. Also, the weather proof design ensures that it can work normally for various demanding outdoor solutions.

The Outdoor Omni-Directional Antenna emits a powerful amplified signal over a 360 degree radius, delivering a strong multidirection signal from an Access Point or a Bridge. If you have multiple locations or buildings where you would like to integrate your wireless network, simply place the TL-ANT2412D in between the buildings with your Access Point. It is most effective when placed at the top of buildings.
Installation of the TL-ANT2412D is simple and straight forward. It is compatible with most wireless devices (Access Points, Routers, Bridges and Network Adapters) on the market with removable external antennas.
ANTENNA
Dimension 1200mm
Weight 0.5kg
Frequency 2.4GHz~2.5GHz
Impedance 50 Ohms
Gain 12 dBi
Radiation Omni-directional
VSWR(MAX.) < 2.0
HPBW/H( °) 360°
HPBW/V( °) 12°
Polarization Linear, Vertical
Connector Type N Female
Mounting Pole Mount / Wall Mount
Application Outdoor
Lightning Protection DC Ground
Operating Temp. -40℃~65℃(-40℉~149℉)
Storage Temp. -40℃~80℃ (-40℉~176℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing
Safety, Emission and Others CE, FCC, Compliant with RoHS
Package Contents 12dBi Outdoor Omni-directional Antenna
Installation mounting kits
User Guide
Frequency Bands WLAN/WiFi 2.4GHz
Frequency range (MHz) 2400-2500
Antenna amplification (dB) 12
Amplifier (dB) N/A
Antenna position Indoor, Outdoor
Antenna direction Omnidirectional
Mast clamp (mm) 22-50
Wall mount included No
Product height (mm) 1200
Product width (mm) 48
Product depth (mm) 48
Product weight (g) 500

Manufacturer product link http://www.tp-link.com/
Warranty 12 months

Specifications
Details
Product code RBSXTsq2nD
Architecture MIPSBE
CPU QCA9533
CPU core count 1
CPU nominal frequency 650 MHz
Dimensions 129 x 129 x 34 mm
License level 3
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C .. +70°C
Powering
Details
Max Power consumption 5W
PoE in Passive PoE
PoE in input Voltage 10-30 V
Number of DC inputs 1 (PoE-IN)
Wireless
Details
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 10
Wireless 2.4 GHz chip model QCA9533
Ethernet
Details
10/100 Ethernet ports 1
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 30 -100
11MBit/s 30 -93
6MBit/s 30 -94
54MBit/s 26 -80
MCS0 30 -94
MCS7 25 -75

Product code:
IH-G0607-F2460-V1
Antenna type:
omnidirectional dual-band 2.4 & 5 GHz
Frequency class:
2.4GHz
5GHz
Frequency (min):
2 400MHz
Frequency (max):
6 000MHz
Gain:
6dBi
7dBi
Gain (max):
7dBi
VSWR (max):
1.70:1
Half Power Beam Width (-3dB) - horizontal:
360°
Half Power Beam Width (-3dB) - vertical:
30°
Cross Polarization Discrimination:
>18dB
Polarization:
Vertical
Impedance:
50Ω
Max Composite Power:
2W
DC Ground:
no
Connector:
N female
Mounting Diameter:
ø 38…62mm
Weight (incl. mount):
0.30kg
Dimensions (excl. mount):
290x26
Enviroment:
Outdoor
Indoor
Windload:
200km/h

This strong external WiFi antenna will catch impor internet to 1000 meters away and connects to PC / laptop.
Wireless USB Network Card WiFi antenna 2,4GHz 58dBi external waterproof and data rates of 150 Mbps with integrated 5m cable.
Stop looking desperately for available networks, the wireless USB network card 2.4GHz WiFi antenna, you will have many options!
If your mobile or laptop displays available networks on your balcony or your terrace, this unique outdoor wifi antenna promises to do much more and more power!
Insert the wireless USB 2,4GHz WiFi network card to the external parts of your site, high on the wall of your balcony below the ledge, if possible to the point of not seeing the sun and to get the best possible shot, drive cable inside your home and connect it to your PC / your laptop.
Most networks that are hundreds of meters of you will be visible!
Connect quickly and safely and at high speeds!
You can still place and home interior near the window

    Wireless network card
    Data transfer rate: 150 Mbps
    Interface: USB 2.0 / 1.1
    IEEE 802.11n, 802.11b / g / n
    MIMO (Multiple Input Multiple Output)
    Operating frequency: 2.4GHz
    58 dbi
    Long range
    5800mW
    Network security: 64/128-bit WEP, WPA, WPA2, TKIP, AES
    Waterproof outdoor antenna
    The package including: 5 m USB cable, antenna base, the accompanying CD ROM
    Compatible with Windows 2000, XP 32/64, Vista 32/64, Windows 7, Mac (10.4.x / 10.5.x / 10.6.x)

Features



Compliant with 802.11n/b/g (2.4GHz)
14dBi signal gain
RP-SMA Male connector
100cm low loss CFD-200 cable


Specifications


Antenna
Frequency 2.4GHz
Gain 14dBi
VSWR(MAX.) 1.5:1
HPBW/H( °) 30
HPBW/V( °) 30
Polarization Linear; Vertical
Type Directional
Connector Type RP-SMA Male
Extended Cable/Length CFD-200 ; 100cm
Mounting Pole Mount/Wall Mount
Application Outdoor
Approximate Range at 1/11/54Mbps 5km/3km/440m
Optional Accessory TL-ANT24EC3S TL-ANT24EC5S
Package Contents 14dBi Panel Directional indoor Antenna
Installation mounting kits
User Guide

Compact and solid patch antenna for 2400MHz Wifi, with 8dBi gain. Suitable for wall or mast mount, including tilt/swivel mount. Intended for use in office areas, cafés, restaurants and other public spaces, where a solid an unobtrusive antenna is required. The antenna is weatherproof and can also be used outdoors. Comes including 20cm cable with N female connector.
Size W x H x D - 125 x 97 x 30 mm

Antenna Specification:
Working band: 2400-2485 MHz
Energy gain: 12 dBi
Impedance: 50 Ω per connector
Antenna connector: 10m low-loss cable with RP-SMA plug
VSWR: <1.5
Radiation angle in the vertical plane: 32 degrees
Radiation angle in the horizontal plane: 35 degrees
Mount: Cybant
Dimensions: 140x120x40mm
Wind resistance: 200km / h
Polarization: Horizontal and vertical
Cable length: 5m
Kit composition:
1. 2.4GHz 12dBi WiFi Panel Antenna
2.5m low-loss cable with RP-SMA plug
3. Mounting brackets for the antenna
